Dimensions |
|
|---|---|
| Usable basket Ø | 1190 mm |
| Usable height | 500 mm |
| Loading height | 1000 mm |
Cleaning |
|
| Washing tank liquid volume | 240 l |
| Liquid volume rinse tank | 150 l |
| Spray pressure wash pump | 5 bar |
| Spray pressure rinsing pump | 3 bar |
Supply |
|
| Connected loads | 230/400 V / 50 Hz |
| Pump motor VA Wash tank | 4 kW |
| Pump motor VA Rinsing tank | 1.5 kW |
| Heating capacity washing tank | 9 kW |
| Heat output rinse tank | 6 kW |
| Rotary basket drive | 0.09 kW |
| 1-stage steam extraction | 0.45 kW |
Dimensions Machine |
|
| Total height (machine) | 1600 mm |
| Total width (machine) | 1500 mm |
| Total depth (machine) | 2550 mm |
Load |
|
| Permissible basket load (surface weight/load increase possible) | 500 kg |
